Prosessorikanta:
Supports 12th/ 13th Gen Intel® Core™ Processors, Pentium®
Gold and Celeron® Processors
Piirisarja:
Intel® Z690 Chipset
Muisti:
4 DIMMs, Dual Channel DDR4-5000+MHz(OC)
Näytönohjain:
Support 4K@30Hz as specified in HDMI™ 1.4b, DisplayPort
1.4 – Requires Processor Graphics
Laajennuspaikat:
3x PCIe 3.0 x1 slots
1x M.2 2230 with E-Key for Wi-Fi Module
Tallennuspaikat:
2x M.2 Gen4 x4 64Gbps slots
supports Intel® Optane™ Technology
4x SATA 6Gbps ports
WLAN:
–
Bluetooth:
–
Audio:
8-Channel (7.1) HD Audio with Audio Boost
USB-portit:
1x USB 3.2 Gen 2×2 20Gbps (1 Type-C)
8x USB 3.2 Gen 1 5Gbps (8 Type-A)
6x USB 2.0
Sisäiset laajennuspaikat:
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
1x 4-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x M.2 slots (M-Key)
2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4 USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector (PWM mode only)
1x 4-pin water-pump fan connector (PWM mode only)
4x 4-pin system fan connectors (PWM mode only)
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Clear CMOS jumper
1x TBT connector (Supports RTD3)
Ulkoiset laajennuspaikat:
DisplayPort
HDMI™
USB 2.0
LAN port
Audio Connectors
USB 3.2 Gen 1 5Gbps Type-A
USB 3.2 Gen 2×2 20Gbps Type-C
USB 3.2 Gen 1 5Gbps Type-A
Optical S/PDIF Out
Muuta:
The latest PCIe 5.0 solution with up to 128GB/s bandwidth for
maximum transfer speed.
