AMD AM5 -kanta
Tukee AMD Ryzen 7000 -sarjan työpöytäprosessoreja
Piirisarja:
AMD B650
Muisti:
4 x DDR5 DIMM, maks. 128GB
Dual Channel -muistiarkkitehtuuri
Tukee: DDR5 ECC/non-ECC, un-buffered memory up to 6400+(OC)
Audio:
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Verkkokortti:
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
Dragon RTL8125BG
Laajennuspaikat:
CPU:
1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode
Chipset:
1 x PCIe 4.0 x16 Slot (PCIE3), supports x2 mode
2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE4)
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
CPU:
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
Chipset:
1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x2 (32 Gb/s) mode
4 x SATA3 6.0 Gb/s Connectors
1 x SPI TPM Header
1 x Power LED and Speaker Header
1 x RGB LED Header
3 x Addressable LED Headers
1 x CPU Fan Connector (4-pin)
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
1 x 24 pin ATX Power Connector
2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
1 x Front Panel Audio Connector
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
1 x Front Panel Type C USB 3.2 Gen2 Header (ReDriver)
2 x Antenna Mounting Points
1 x HDMI Port
1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (ReDriver)
7 x USB 3.2 Gen1 Ports (USB32_34 are Lightning Gaming Ports) (USB32_12 and USB32_56 are from ASMedia ASM1074 hub)
4 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x BIOS Flashback Button
HD Audio Jacks: Line in / Front Speaker / Microphone
Microsoft® Windows® 10 64-bit / 11 64-bit
ATX (30,5 x 24,4 cm)
